REVO FORD FOCUS RS MK3 ECU | 2.3 TURBO
- Stage 2 Performance Pack: 405WHP / 600NM Technical Data
- Launch Limit reduced to 4500RPM
- Speed Limit Removed
- RPM Limit raised to 7000 RPM
- Shift indicator light optimised
- Temperature related protection
Performance data from DynaPack 4 wheel hub Dyno Peak and Maximum Gains between stock (running overboost) to Stage 2 Performance Pack. Results can't be guarenteed with Third party non Revo hardware.
Added Protection
During testing it quickly came to light that the 2.3 EcoBoost engine suffers considerably with high temperatures. This not only affects the top-end power output of the engine but can also cause considerable damage. To prevent this from happening, our calibration team have incorporated Temperature Protection, an additional safety feature that limits engine power under extreme temperatures before damage to the engine. Temperature Protection Feature
Revo Stage 1 tuning is developed to work within the constraints of the standard engine; we could run more boost and power, but not reliably or consistently on an otherwise standard vehicle. Our testing indicated that this engine struggles with heat management; in high-temperature conditions (Rolling Road, High ambient temps, and prolonged vmax/track use) intake air temperatures (IAT) climb very quickly without additional cooling modifications.
We have implemented additional safety features by reducing overall power as IAT's climb to undesirable levels.
- IAT over 60ºC, power is reduced by 5%
- IAT over 65ºC, power is reduced by 10%
- IAT over 70ºC, power is reduced by 15%
This feature also actively monitors exhaust gas temperatures (EGT). If EGT's begin to rise towards unsafe levels then power is automatically reduced by up to 10% until the engine reaches a safe operating temperature.
Added Features
The calibration team at Revo have studied the RS's ECU in depth and integrated features that offer Revo ECU performance software beyond just figures. Shift Light
The shift light has been optimised for Revo stage 2 software and now indicates the best shift point based on the improved tuning. The "RS" light now comes on at 6200RPM where the power is at its peak, it then starts Flashing at 6500RPM to indicate optimal power is decreasing. Switchable Software
Using an SPS switch you are able to take advantage of the switch-ability of Revo software. The Patented OBD2 interface is the ultimate compliment to our performance software, giving the user the ability to switch between 2 fuel quality modes (97RON and 98RON) and a stock performance setting via the vehicle OBD port, along with the benefit of a security lockout program (anti-theft). This anti-theft feature will allow the car to be started but then will not idle or run.
Simply select a program, plug in, wait a few seconds, remove the SPS device and start the car. It's simple and there's no fixed switch to install in the vehicle. Find out more about the Revo SPS.
The Revo Difference OBD Port Install Revo Software can be installed quickly and safely via the OBD Port without the need to open the ECU. 30 Day Guarantee We know you'll love how Revo Software transforms your car. If you don't, we'll give you your money back. Fuel Economy Dependent on your driving style, this software will deliver like for like fuel economy in 'normal' driving conditions.
