Voyager-12W

Caravan Specifications Dimensions & Weight

Width: 2100mm

Height (Roof Closed): 2350mm

Length (Hitch to Taillights): 5500mm

Ball Weight: 130kg

Tare Weight: 2100kg

GTM: 3000kg Construction

Drawbar: Hot-dip galvanized (inside & outside), 150mm × 50mm × 4mm Q345

Chassis: Hot-dip galvanized (inside & outside), 150mm × 50mm × 3mm Q345

Body: Aluminium composite panel with aluminium checker plate

Structure: Fully welded frame and chassis

Finish: Composite aluminium panels with powder-coated aluminium chequer plate Suspension & Running Gear

Suspension: Independent arm suspension with 4 × auto kick-back shock absorbers

Wheels & Tyres: 4 × 1550kg alloy wheels with 265/75 R16 tyres

Rims: Stainless steel aluminium alloy

Spare Tyres: Double spare tyre holder with 265/75 R16 tyres and alloy wheels Tow & Safety

Coupling: Standard coupling

Brakes: 4WD 12" electric brakes with hand brake

Stone Guard: Included, with stone tamer mudflaps

Jockey Wheel: 10" swing-up

Stabiliser Legs: 4 × heavy-duty, lockable, adjustable drop-down legs

Light Connection Plug: 7-pin round or 7-pin flat Gas & Water System

Gas Holder: 2 × 9.5kg

Water Tanks:

85L 35L fresh/green water

85L grey water

Water Delivery: Truma 14L gas/electric hot water service with 12V pump, fully plumbed

Shower (External): Hot/cold with van-mounted shower tent

Shower Room (Internal): Internal shower with Thetford toilet Electrical System

Batteries: 3 × 100Ah lithium

Charger: 240V battery charger (1pc)

Inverter: 2000W pure sine wave

Solar Panels: 3 × 100W

240V Outlets: Included

Diesel Heater: 1pc

Interior Lighting: Multiple LED lights

Exterior Lighting: LED tail lights and LED number plate light

Bed Lighting: 2 × LED reading lights Living & Comfort

Mattress: 200mm custom queen-size foldable innerspring

Table: Portable table

Awning:

Electric awning with manual override

Full set annex walls and floor

Kitchen: External 304-grade stainless steel sink with 4-burner stovetop

Fridge: Not included

Storage: 2 large storage boxes

Door: Lockable security screen door

Caravan windows with anti-mosquito mesh and shade curtains Media & Connectivity

Stereo: Marine-grade with 4 speakers

TV: Wall-mounted with antenna plugs (inside & outside)
