Industrial Solar Charge Controller - Phocos CIS-MPPT-20 Amp - Waterproof IP68

The highly efficient German-designed Phocos CIS-MPPT solar charge controller is perfect for all larger marine solar systems, caravan solar panel systems and rural solar systems.

Phocos’ innovative MPPT technology yields up to 30% more energy than PWM ontrollers. In addition, their signature Power ™ current limiter allows for oversizing PV power by up to 50% for winter months without damage in summer months. The CIS-MPPT controllers are optimized to work with 60-cell modules. They ensure maximum performance and yield from all types of PV systems year-round and in any environment. Phocos’ CIS-MPPT controllers are equipped with 2 year datalogging memory.

Application Examples
• SCADA Systems
• RVs
• Solar Message Boards
• Solar Lighting
• Security/Surveillance
• Wifi/Repeater Stations
• Transportation

Please note the controller has negative grounding.

With a sealed IP68 waterproof housing, 98 percent efficiency and a 5-year manufacturers' warranty, it is built to last.

Data Sheet: https://www.phocos.com/wp-content/uploads/2019/12/CIS-MPPT-Datasheet.pdf

The Phocos CIS MPPT is both ROHS and CE compliant. Specifications 12 Volt / 24 Volt System Voltage 12/24 V Auto Recognition Max Charge / Load Current 20 Amps Battery Type Lead Acid (gel, AGM, flooded) Ingress protection IP68 Solar Input 85 Volts 400 Watts/800 Watts Grounding Please note Negative Dimensions 148 x 152 x 43 mm Float Charge 13.8/27.6 V (25 °C) Main Charge 14.4/28.8 V (25 °C), 0.5 h daily Boost Charge

14.4/28.8 V (25 °C), 2 h activation:< 12.1/24.2 V Deep discharge Protection 11.0 - 11.9 /22.0 - 23.8 V Over Voltage Protection 15.5/31.0 V Under Voltage protection 10.5/21.0 V Temperature Compensation -25 mV/degree/ -50 mV/degree Idle self consumption 15 mA/8 mA Certifications CE compliant, RoHS compliant, IEC-62509 Warranty 5 years

For more information see the Phocos website.
