Fixing Clips

- Fixing clips compensate for irregularities in bore and diameter.
- Ideal where only single-sided access to the mounting surface is reachable. Optimal Retantion ≥ 3mm
- Fit clip to mounting bore.
- Push ball unit though clip.
- Peripheral tags expand & grip the ball unit.
K-clip Spring Steel
C-clip Stainless Steel Other clips available. Switch measurements: Metric (mm/kg) Imperial (inch/lb) Light Duty Medium Duty Clip Bore Ø MIN / MAX A £ from Files M12 - MI12 K12 0.905 - 0.925 23.0 - 23.5 0.866 22 £ PDF Step L15 - LP15 M14 - M15 - MI15 - MG15 K15 0.984 - 1.004 25.0 - 25.5 0.945 24 £0.67 PDF Step L15 - LP15 M14 - M15 - MI15 - MG15 C15 0.976 – 0.984 24.8 - 25.0 0.945 24 £0.91 PDF Step L22 - LP22 M22 - MI22 - MG22 K22 1.457 - 1.476 37.0 - 37.5 1.417 36 £0.78 PDF Step L22 - LP22 M22 - MI22 - MG22 C22 1.457 - 1.465 37.0 - 37.2 1.417 36 £1.05 PDF Step L30 - LP30 M30 - MI30 - MG30 - MV30 - MX30 - MW30 K30 1.81...
