TREVOLI - CVF20-5 - Stainless Steel Vertical Multistage Water Pump with Variable Speed Controller
CVF20-5VP
This pump is ideal for high volume medium head applications such as washdown. Fitted with a variable speed constant pressure controller and 18L pressure tank. Specifications:
Power -5500W - 7.37 Horsepower
Three phase
Max Flow rate: At 500 litres per minute
Max Pressure: 102 psi
Max discharge head: 71 metres
Max suction 1.5m
Inlet size: 2inch BSP (50mm)
Outlet size: 2 inch BSP (50mm)
Built in thermal overload protection
Insulation class F
IP55 Protection
Rated for Continuous duty
Liquid temperature range: -20 - 104 deg C
Max operating pressure: 16 bar
Height: 969 mm
Weight: 83 Kg (pump only) Common Applications:
Domestic water supply for large / very large homes
Farm irrigation
General water transfer systems
Industrial/commercial applications Features:
Fitted with a variable speed constant pressure controller
Delivery pressure can be easily adjusted at any time
Controller provides soft starts to avoid water hammer and related problems
Pump motor operates at varying speed based on actual demand saving up to 50% electricity usage
Run Dry Protection
Corrosion resistant stainless steel construction
Stainless steel pump housing
Stainless steel motor shaft
Stainless steel impeller and intermediate chambers
Build in thermal overload protection
Quiet operation
2 Year back to base warranty
CVF Series Brochure
