Vacuum former model 242

SKU: CL242 Categories: Recycling Equipment, Vacuum Formers Tags: c r clarke, model 242 vac former, techspan australia, techspan group, techspan new zealand, vacuum former, vacuum former 242

- Product Enquiry

The 242 vacuum former is a semi-automatic single sided heater, vacuum former for sheets up to 686 x 660mm (27 x 26in), with a maximum thickness of 6mm (0.25in). Smaller sheet sizes are accommodated by additional, easily fitted reducing frames.

The maximum mould height is 300mm (12").

The heater hood contains ceramic elements grouped into 15 zones controlled by a PLC. During the heating cycle pressure balancing maintains sheet level, ensuring consistent heating over the whole area.

The PLC controls the heater zones, the movement of the heater hood, platen and clamp frame, and the vacuum/blow cycles. Heat settings are adjusted in 1% increments and heating/vacuum /blow cycles are controlled in 0.1 second increments. Up to 40 heate...
