Dual Sky ECO 2820C 1120kv 540w Brushless Outrunner Motor 25E 138g 10x6 - 12x5E

Product Name: ECO 2814C-V2 Brushless Motor
SKU: 51660
KV Rating: 1120 KV
Turns: 6.5
Weight: 105 g
Dimensions (D × L): 35.2 × 34.2 mm
Slots & Poles: 12N14P
Internal Resistance (Ri): 37.8 mΩ
No-load Current (Io @10V): 1.2 A
LiPo Cell Count: 2–3S
Max Efficiency Current: 22 A
Burst Current (15s): 36 A
Peak Power (15s): 432 W
Peak Torque: 0.37 N·m
Shaft Diameter: 5 mm
Mounting Hole Pitch: 19/19 mm
Input Connectors: GC3.5
Recommended ESC: XC-45-LITE or XC4018BA
Recommended Propellers:

- 3S: 9×6E, 10×6E
- 4S: 11×4.5E

Class:.10–.15 Class
